Forklift Alternators and Starters - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid mounted on it. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is situated on the driveshaft and meshes the pinion utilizing the starter ring gear which is seen on the flywheel of the engine.
When the starter motor starts to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid consists of a key operated switch which opens the spring assembly to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in just a single direction. Drive is transmitted in this particular way via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for example since the driver fails to release the key as soon as the engine starts or if the solenoid remains engaged in view of the fact that there is a short. This causes the pinion to spin separately of its driveshaft.
This aforesaid action stops the engine from driving the starter. This is an essential step as this particular type of back drive would allow the starter to spin very fast that it can fly apart. Unless adjustments were made, the sprag clutch arrangement will prevent making use of the starter as a generator if it was employed in the hybrid scheme mentioned earlier. Usually a regular starter motor is designed for intermittent use that would stop it being utilized as a generator.
The electrical parts are made so as to work for approximately thirty seconds to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are designed to save cost and weight. This is truly the reason nearly all owner's handbooks meant for vehicles suggest the operator to pause for a minimum of 10 seconds after every ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.
The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Prior to the 1960's, a Bendix drive was utilized. This drive system works on a helically cut driveshaft that has a starter drive pinion placed on it. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, therefore engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design which was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights within the body of the drive unit. This was a lot better in view of the fact that the average Bendix drive utilized to be able to disengage from the ring when the engine fired, although it did not stay running.
As soon as the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be avoided before a successful engine start.
